UV Exposure machine
- Multi-Function, All in One machine.
- Dry film, Wet film is acceptable.
- Suitable for both Inner/Outer Layer and Solder Mask.
- High resolution:2mil, Solder mask All colors ink:3mil.
- LED light source long service life,Up to 25,000 hours.
- Stable Quality and performance
Manual UV exposure machine with different Exposure Size
The manual UV exposure machine is designed for processing PCB circuit and Solder Mask, it can be customized to do dry film only, and also can All in One machine to process Wet film, solder mask all colors. KST Optical has different models, differnt exposure size to meet your needs on different size PCB.
All In One machine
Process: Both dry film /Wet film
And all colors Solder mask
Resolution:2mil/50um
Working table: Double drawers
Process: Both dry film /Wet film
And all colors Solder mask
Solder Dam:3mil/75um
Working table:Double drawers
All In One machine
Process: Both dry film /Wet film
And all colors Solder mask
Resolution:2mil/50um
Working table: Double drawers
Process: Both dry film /Wet film
And all colors Solder mask
Solder Dam:3mil/75um
Working table:Double drawers
Select the Right Model for your PCB production
| Model | KST-E10070-XL | KST-E12570-XL | KST-E15070-XL |
|---|---|---|---|
| Exposure Area | 1060×700 | 1250×700 | 1500×700 |
| LED light | Multiple Wavelength UV LED×2 | Multiple Wavelength UV LED×2 | Multiple Wavelength UV LED×2 |
| Resolution | 2mil/50um | 2mil/50um | 2mil/50um |
| Model | KST-F10065-BLZX | KST-F12565-BLZX | KST-F15065-BLZX |
|---|---|---|---|
| Exposure Area | 1060×650 | 12565×650 | 1500×650 |
| LED light | Multiple Wavelength UV LED×6 | Multiple Wavelength UV LED×6 | Multiple Wavelength UV LED×6 |
| Resolution | 3mil/75um | 3mil/75um | 3mil/75um |
Dry Film Resolution
Solder Mask Opening/Bridge
UV LED Light Sources
Processing different colors ink
- Multiple Wavelength UV-LED
- Optional,Dry film and Solder Mask for selection.
- LED Light Instant ON/OFF, Reduce Engergy Costs.(Lift time better than Mercury UV-LAMP).
- Long service life ＞20,000 hours.
What's UV exposure machine, And How to use this machine to make PCB?
The UV exposure machine is a machine that transfers the image information on the film or other transparent body to the surface coated with light-sensitive materials(Copper or FR4, aluminum substrate)by turning on the uv light.
Buy UV LED exposure machine, You save money in many ways!
- Less energy required and very short exposure times. Saving your money on utility cost.
- Less money for bulbs. Saving your money in maintenance cost .
- Less heat generated during operation. Saving your money in facility cooling cost.
- Less down time due to bulb issues. Saving your money and stress.
- less scrap rate in the process of the production. Saving your money and improve the production efficiency.
KST CNC Workshop
Why Choose KST UV Exposure machine?
- Small Footprint
Simple structure, occupying less space for more equipment.
- Widely use
Widely use in PCB production and etching production.
- Energy Saving
All the light source are LEDs, super energy saving.
- Cost-effective
LED Light sources are long services life >20,000 hours. Saving your money in maintenance cost .
- Easy To Fix
Due to simple structure. All the parts are easy to remove and replace.
- Low Labor Cost
It can run regularly, one worker run with two working tables, easy to operate and low labor cost.
